Details
Whether you're looking ahead to park days, staring down a rocky line you’re determined to conquer, or preparing for your first enduro race – the all-new Intrigue LT equips you with the versatility of adjustable frame geometry, the durability of ALUXX SL-grade aluminum and the ultra-smooth performance of Maestro suspension so you can say “YES!” to it all.
Key Performance Factors:
Performance Long Travel Trail
Lightweight Advanced-grade composite frameset with integrated down tube storage features a slacker head tube angle for confidence on technical terrain and a longer reach to keep you centered and in control in the corners. The 150mm of Maestro rear wheel suspension has been custom tuned by women who shred, for women who shred. And paired with 160mm of front suspension, you’ve got a bike that is equal parts agile and burly.
Adjustable Frame Geometry
All-new flip chip – Maestro 3 offers more adjustability allowing you to easily change the head tube and seat tube angles, bottom bracket height and rear wheel size* to fine-tune handling for varying trail conditions and your personal riding style. *Sizes M and L only
Best of Both Wheels
Frame sizes XS and S are solely designed for a MX configuration – 29-inch wheel up front and 27.5-inch wheel in the rear. This set up optimizes rear wheel travel, provides a playful and nimble rear end and a fast rolling, stable front end. Frame sizes M and L come equipped with 29-inch wheels up front and in the rear with the ability to run a 27.5-inch wheel in the rear. This provides two unique riding characteristics – fast and comfortable or quick and nimble – allowing you to customize your set up for how and where you ride. *27.5-inch wheel sold separately for frame sizes M and L
Frame Size | X-Small | Small | Medium |
---|---|---|---|
Geometry Position | LOW | MID | HIGH | LOW | MID | HIGH | LOW | MID | HIGH |
Seat Tube Length (mm) | 370 | 390 | 420 |
Seat Post Insertion Depth (mm) | 230 | 250 | 280 |
Seat Tube Angle | 76.2° | 76.6° | 77.0° | 76.2° | 76.6° | 77.0° | 77.3° | 77.6° | 78.0° |
Top Tube Length (mm) | 552 | 552 | 550 | 567 | 566 | 565 | 581 | 580 | 579 |
Head Tube Length (mm) | 95 | 95 | 100 |
Head Tube Angle | 64.7° | 65.1° | 65.5° | 64.6° | 65.1° | 65.5° | 64.8° | 65.1° | 65.5° |
Fork Rake (mm) | 44 | 44 | 44 |
Trail (mm) | 131 | 127.9 | 124.8 | 131.6 | 127.8 | 124.8 | 130.6 | 127.7 | 124.8 |
Wheelbase (mm) | 1166 | 1166 | 1164 | 1183 | 1180 | 1179 | 1208 | 1207 | 1207 |
Chain Stay Length (mm) | 443 | 442 | 440 | 443 | 442 | 440 | 443 | 442 | 440 |
Bottom Bracket Drop (mm) | 25 | 20 | 15 | 24 | 20 | 15 | 35 | 30 | 25 |
Stack (mm) | 629 | 627 | 624 | 628 | 627 | 624 | 628 | 625 | 622 |
Reach (mm) | 398 | 402 | 406 | 413 | 417 | 421 | 439 | 442 | 447 |
Stand Over Height (mm) | 613 | 613 | 613 | 674 | 674 | 674 | 712 | 712 | 712 |
Handlebar Width (mm) | 760 | 760 | 760 |
Stem Length (mm) | 40 | 50 | 50 |
Crank Length (mm) | 165 | 170 | 170 |
Wheel Size | F 29 | R 27.5 | F 29 | R 27.5 | 29" |
Frame Size | Rider Height (cm) | Rider Height (in) |
---|---|---|
X-Small | 150 - 163 | 4'11" - 5'4" |
Small | 158 - 169 | 5'2" - 5'7" |
Medium | 164 - 175 | 5'5" - 5'9" |
Specs
Pedals | Sold Separately |
---|---|
Fork | Fox 38 Performance Elite, 170mm, GRIP2 damper, 44mm offset, 15x110mm Kabolt, custom tuned for Liv |
Hubs |
[F] Giant MTB alloy, 6-bolt, sealed [R] Giant MTB alloy, 6 bolt, 72t POE, sealed, XD driver |
Rims | Giant TRX WheelSystem, carbon, hookless, 30mm IW, 40mm OW, 22mm H, Wide Guard Technology |
Stem | Giant Contact SL 35 |
Chain | SRAM GX Eagle Transmission |
Frame | Advanced-grade composite front and rear triangles, 150mm Maestro Suspension, flip chip – Maestro 3, 12x148mm thru-axle, integrated down tube storage |
Tires |
[F] Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless XS, S [R] Maxxis Dissector 27.5x2.4WT, 3C Max Terra, EXO, TR, tubeless M [R] Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless |
Brakes |
TRP EVO DH-R HD-M846, hydraulic Shimano RT-66 rotors, [F]203mm, [R]180mm |
Saddle | Liv Sylvia |
Spokes | Sapim Laser straight pull, DBL technology |
Crankset | SRAM GX Eagle Transmission, 30t, 55mm chainline |
Seatpost |
Giant Contact Switch AT adjustable dropper, remote XS, S: 140-170mm travel/ 30.9x470mm M: 170-200mm travel/30.9x530mm |
Shifters | SRAM AXS Pod, discrete clamp, 1x12 |
Handlebars | Giant Contact SLR TR35, composite, 20mm rise, 35mm |
Tape/Grips | Liv Tactal single lock-on |
Brake Levers | TRP EVO DH-R |
Bottom Bracket | SRAM DUB, press fit |
Rear Derailleur | SRAM GX Eagle Transmission AXS |
Accessories & Extras | MRP AMG CS chain guide, 3M tailgate protector, tubeless prepared, integrated down tube storage bag, max tire size 2.5", max chainring size 32t |
Cassette/Freewheel | SRAM GX Eagle Transmission, 12-speed, 10x52 |
Rear Shock | Fox Float X Performance Elite 185/55, 2-position, custom tuned for Liv |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Raw Carbon / Small / 29-inch | 4711291146990 | 1059017104 | 25I30245357N |
Raw Carbon / X-Small / 29-inch | 4711291146983 | 1059017103 | 25I3134289N |
